Model No: U310 /G
three phase input and single single out UPS
U310 /G series three phase input and single single out UPS is the company's collection of industry customers for many years of application requirements, experience and the latest research and development results, designed and manufactured a new generation of dual-conversion low frequency online UPS, effectively improve product safety and system reliability, and achieve higher power density integration, intelligence and miniaturization.
Quantity :
U310 /G series three phase input and single single out UPS is the company's collection of industry customers for many years of application requirements, experience and the latest research and development results, designed and manufactured a new generation of dual-conversion low frequency online UPS, effectively improve product safety and system reliability, and achieve higher power density integration, intelligence and miniaturization.
Application
Applicable to finance, telecommunications, securities, taxation, transportation, insurance, government, building lighting, road traffic lighting, electricity, industrial and mining enterprises and other industries.
Applicable to finance, telecommunications, securities, taxation, transportation, insurance, government, building lighting, road traffic lighting, electricity, industrial and mining enterprises and other industries.
Characteristic
High-speed microcontrollers and programmable logic devices are used to achieve circuit control, parameter setting, operation management, advanced self-test and self-detection functions, which can self-test and fault analysis of all independent circuit connections on the circuit board. Through digital conversion of sine wave voltage, a new perfect operation scheme to meet the actual needs of users.
Efficient IGBT inverter technology
IGBT good high-speed switching characteristics; With high voltage and high current operating characteristics; Using voltage drive, only need a small control power; The fifth generation IGBT has a lower saturation voltage drop, and the inverter is more efficient and reliable.
High-speed microcontrollers and programmable logic devices are used to achieve circuit control, parameter setting, operation management, advanced self-test and self-detection functions, which can self-test and fault analysis of all independent circuit connections on the circuit board. Through digital conversion of sine wave voltage, a new perfect operation scheme to meet the actual needs of users.
Efficient IGBT inverter technology
IGBT good high-speed switching characteristics; With high voltage and high current operating characteristics; Using voltage drive, only need a small control power; The fifth generation IGBT has a lower saturation voltage drop, and the inverter is more efficient and reliable.
Superior load characteristics
Fully meet the load jump from 0 to 100% without switching to bypass, and protect the output stable and reliable.
Fully meet the load jump from 0 to 100% without switching to bypass, and protect the output stable and reliable.
Humanized large screen LCD Chinese and English display
Large screen Chinese and English menu, flow chart running status intuitive display, flexible implementation of human-machine dialogue function. Intuitive LED status indicator, workflow program status indicator, which are quite clear.
Large screen Chinese and English menu, flow chart running status intuitive display, flexible implementation of human-machine dialogue function. Intuitive LED status indicator, workflow program status indicator, which are quite clear.
High-performance dynamic features
By adopting instantaneous control and RMS feedback control, high dynamic adjustment is realized and the distortion of output voltage is reduced.
By adopting instantaneous control and RMS feedback control, high dynamic adjustment is realized and the distortion of output voltage is reduced.
Perfect protection function
Input and output over and under voltage protection, input surge protection, phase sequence protection, battery low voltage protection, output over protection, high temperature protection and other system protection and alarm functions.
Input and output over and under voltage protection, input surge protection, phase sequence protection, battery low voltage protection, output over protection, high temperature protection and other system protection and alarm functions.
Intelligent battery management
Intelligent battery charging: Automatically adjust battery charging parameters according to the user's battery configuration, and perform equal-charge floating charge conversion, temperature compensation charging, and discharge management according to the power supply environment. Extend battery life and reduce the burden on administrators.
A 6-pulse (optional 12-pulse) rectifier charger is used to add an input harmonic filter
Effectively suppress the input harmonic pollution, improve the input power factor of UPS power supply, reduce the input harmonic
current.
Effectively suppress the input harmonic pollution, improve the input power factor of UPS power supply, reduce the input harmonic
current.
Intelligent monitoring
RS232 and RS485 communication terminals truly enable multi-purpose communication and remote monitoring. Optional SNMP card for remote monitoring and network management; Optional dry contact port that uses passive contacts to monitor the UPS status.
RS232 and RS485 communication terminals truly enable multi-purpose communication and remote monitoring. Optional SNMP card for remote monitoring and network management; Optional dry contact port that uses passive contacts to monitor the UPS status.
