Model No: U110/G
Single phase input and single phase output low frequency Online UPS
U110/G series is specifically designed for network computer rooms and small intelligent equipment in finance, communication, insurance, transportation, tax, military, securities, energy, education, government and enterprise systems
Quantity :
U110/G series is specifically designed for network computer rooms and small intelligent equipment in finance, communication, insurance, transportation, tax, military, securities, energy, education, government and enterprise systems. It is also suitable for measuring devices, industrial automation equipment, precision instruments and it is the third-generation
power frequency true online intelligent UPS systems. This UPS utilizes an online double conversion extension spectrum
architecture design and is especially well-suited for harsh power grid environments. It provides reliable power protection for enterprise servers, small to medium-sized local area networks and precision electronic instruments in line with the application
concept of prioritizing stability above all else. Undoubtedly , choosing YZ-U110/G series UPS is your one of best choices.
Characteristic
· Using SPWM pulse width modulation technology, IGBT power module and input and output isolation
transformer, UPS output is free from power grid fluctuation interference, low distortion of pure sine wave power supply. · Double conversion technology and static electronic bypass technology are adopted to realize 0 conversion
time. It has a variety of system protection and alarm functions such as input and output over-voltage
protection, input surge protection, phase sequence protection, battery over-charge and over-discharge
protection, output overload and short-circuit protection, and over-temperature protection. · Ultra-wide input voltage, frequency range, reduce the circles of battery discharge, extend the battery life. · Super cold start function, in the case of no mains power, cold start can be fully loaded to meet the
emergency power requirements · A variety of feedback controls, such as instantaneous control mode and effective value, are adopted to achieve high dynamic
adjustment, reduce waveform distortion to fully meet the load jump from 0 to 100%, without switching to bypass, and ensure
stable and reliable output.
Humanized interface, man-machine communication barrier Free
• Intuitive LCD display: UPS model, input and output voltage, frequency, load capacity, battery capacity, internal temperature, working status, working mode and fault status, etc. • Friendly man-machine interface design, using LCD LCD display, UPS operation status - eye clear, so that man-machine
communication zero distance.
· Using SPWM pulse width modulation technology, IGBT power module and input and output isolation
transformer, UPS output is free from power grid fluctuation interference, low distortion of pure sine wave power supply. · Double conversion technology and static electronic bypass technology are adopted to realize 0 conversion
time. It has a variety of system protection and alarm functions such as input and output over-voltage
protection, input surge protection, phase sequence protection, battery over-charge and over-discharge
protection, output overload and short-circuit protection, and over-temperature protection. · Ultra-wide input voltage, frequency range, reduce the circles of battery discharge, extend the battery life. · Super cold start function, in the case of no mains power, cold start can be fully loaded to meet the
emergency power requirements · A variety of feedback controls, such as instantaneous control mode and effective value, are adopted to achieve high dynamic
adjustment, reduce waveform distortion to fully meet the load jump from 0 to 100%, without switching to bypass, and ensure
stable and reliable output.
Humanized interface, man-machine communication barrier Free
• Intuitive LCD display: UPS model, input and output voltage, frequency, load capacity, battery capacity, internal temperature, working status, working mode and fault status, etc. • Friendly man-machine interface design, using LCD LCD display, UPS operation status - eye clear, so that man-machine
communication zero distance.
Strong compatibility
• The wide input range and frequency range of the mains reduces the requirements of the UPS for the input mains, and can
be compatible with any form of power, including industrial power generation, wind power generation and other applications. • The output and the power grid achieve accurate zero phase synchronization, to meet the high requirements of many devices for power supply and the power grid, in order to benefit the rural power grid or small fuel generator power supply work. Intelligent communication tools for remote monitoring
• RS232 and RS485 communication ports truly realize multi-purpose communication and remote monitoring; The
optional dry contact port uses passive contacts to effectively monitor the UPS status. Through the DB9 dry junction
port, major abnormal information of the UPS can be extracted through the dry junction. • Optional SNMP card, 100% remote monitoring and network management, can easily achieve intelligent monitoring
of UPS, including short-range point-to-point communication monitoring, medium-distance communication monitoring
and long-distance network monitoring; The real-time monitoring of UPS operating status and operating parameters
is realized. It has many functions such as automatic paging, sending E-MAIL and voice functions, and remote
switching of UPS. Extremely environmentally friendly
•Adopt green rectification and inverter technology to provide users with clean energy. •The whole machine adopts advanced anti-electromagnetic interference technology, which meets international
standards and has good electromagnetic compatibility, minimizing or even eliminating electromagnetic
interference caused to the equipment.
• The wide input range and frequency range of the mains reduces the requirements of the UPS for the input mains, and can
be compatible with any form of power, including industrial power generation, wind power generation and other applications. • The output and the power grid achieve accurate zero phase synchronization, to meet the high requirements of many devices for power supply and the power grid, in order to benefit the rural power grid or small fuel generator power supply work. Intelligent communication tools for remote monitoring
• RS232 and RS485 communication ports truly realize multi-purpose communication and remote monitoring; The
optional dry contact port uses passive contacts to effectively monitor the UPS status. Through the DB9 dry junction
port, major abnormal information of the UPS can be extracted through the dry junction. • Optional SNMP card, 100% remote monitoring and network management, can easily achieve intelligent monitoring
of UPS, including short-range point-to-point communication monitoring, medium-distance communication monitoring
and long-distance network monitoring; The real-time monitoring of UPS operating status and operating parameters
is realized. It has many functions such as automatic paging, sending E-MAIL and voice functions, and remote
switching of UPS. Extremely environmentally friendly
•Adopt green rectification and inverter technology to provide users with clean energy. •The whole machine adopts advanced anti-electromagnetic interference technology, which meets international
standards and has good electromagnetic compatibility, minimizing or even eliminating electromagnetic
interference caused to the equipment.
