Model No: U330 Series
3 phase in 3 phase out low frequency ups
3 phase in 3 phase out low frequency ups
Quantity :
Characteristic introduction
High-speed microcontrollers and programmable logic devices are used to achieve circuit control, parameter setting, operation management, advanced self-test and self-detection functions, which can self-test and fault analysis of all independent circuit connections on the circuit board. Through digital conversion of sine wave voltage, a new perfect operation scheme to meet the actual needs of users.
High-speed microcontrollers and programmable logic devices are used to achieve circuit control, parameter setting, operation management, advanced self-test and self-detection functions, which can self-test and fault analysis of all independent circuit connections on the circuit board. Through digital conversion of sine wave voltage, a new perfect operation scheme to meet the actual needs of users.
Application
Widely used in building lighting, road traffic lighting, electric power, industrial and mining enterprises, centralized server room, network management data center and computer center, industrial automation.
Widely used in building lighting, road traffic lighting, electric power, industrial and mining enterprises, centralized server room, network management data center and computer center, industrial automation.
Characteristic introduction
·· Advanced multi-DSP processor, MCU, CPLD combined with intelligent modern control technology to meet the needs of high-quality power supply.
·· Excellent performance index output, voltage stability accuracy is less than 1%, linear load THDU is less than 1%, but also has super overload capacity and anti-short circuit ability.
·· Support lead acid, lithium battery and other types of battery access, intelligent pool management scheme.
·· system modular design, all-front operation is easy to maintain, intelligent fault information diagnosis function, historical records can be checked, data can be exported and analyzed easily.
·· Intelligent no-master-slave parallel current sharing control technology can realize a maximum of 8 machines without master-slave autonomous parallel operation, which is easy to expand the system.
·· Advanced multi-DSP processor, MCU, CPLD combined with intelligent modern control technology to meet the needs of high-quality power supply.
·· Excellent performance index output, voltage stability accuracy is less than 1%, linear load THDU is less than 1%, but also has super overload capacity and anti-short circuit ability.
·· Support lead acid, lithium battery and other types of battery access, intelligent pool management scheme.
·· system modular design, all-front operation is easy to maintain, intelligent fault information diagnosis function, historical records can be checked, data can be exported and analyzed easily.
·· Intelligent no-master-slave parallel current sharing control technology can realize a maximum of 8 machines without master-slave autonomous parallel operation, which is easy to expand the system.
