Model No: U310/H
There phase input and single phase output high-frequency Online UPS
YZ-U310/H series UPS is Three-phase input and single-phase output UPS, including 10kVA, 15kVA,and 20kVA.This series of UPS adopts dual conversion true online architecture, which is the most effective architecture design to solve all power supply problems.
Quantity :
There phase input and single phase output high-frequency Online UPS
U310/H series UPS is Three-phase input and single-phase output UPS, including 10kVA, 15kVA,and 20kVA.This series of UPS adopts dual conversion true online architecture, which is the most effective architecture design to solve all power supply problems. It can provide good solutions for power grid outage, mains voltage which is too high or too low, voltage transient or damping shock, high voltage pulse, voltage fluctuation, surge voltage, harmonic distortion, clutter interference, frequency fluctuation and other problems to provide the safe and reliable power supply guarantee for load.
Applications
It is suitable for small and medium-sized data centers, enterprise server rooms, control centers in manufacturing, transportation, energy and other fields, as well as precision production and test equipment for industrial fields (such as SMT mounter) as key equipment for power supply and protection.
U310/H series UPS is Three-phase input and single-phase output UPS, including 10kVA, 15kVA,and 20kVA.This series of UPS adopts dual conversion true online architecture, which is the most effective architecture design to solve all power supply problems. It can provide good solutions for power grid outage, mains voltage which is too high or too low, voltage transient or damping shock, high voltage pulse, voltage fluctuation, surge voltage, harmonic distortion, clutter interference, frequency fluctuation and other problems to provide the safe and reliable power supply guarantee for load.
Applications
It is suitable for small and medium-sized data centers, enterprise server rooms, control centers in manufacturing, transportation, energy and other fields, as well as precision production and test equipment for industrial fields (such as SMT mounter) as key equipment for power supply and protection.
Characteristic
·True online double conversion
·Ultra-wide mains input range (190V- 520V)
·The output frequency can be optionally adjusted to 50Hz/60Hz
·Emergency power off (EPO)
·Ultra-wide mains input range (190V- 520V)
·The output frequency can be optionally adjusted to 50Hz/60Hz
·Emergency power off (EPO)
·Compatible with Generator
•SNMP+USB+RS232Multiple monitoring
·Bypass maintenance design (optional)
·Output PF to be 1
