Modular UPS Introduction
UM three in three out UPS, the product adopts modular design and N + X parallel redundancy technology, the
product capacity covers 20k to 300k between the various power bands, convenient for users to configure flexible
and progressive investment. This series of UPS can solve almost all power problems, such as power failure, utility
high-voltage, utility low-voltage, instantaneous voltage drop, amplitude reduction oscillation, high-voltage pulse, voltage fluctuations, surge voltage, harmonic distortion, clutter interference, frequency fluctuations and other power problems.

Features

Digital control

This series of UPS adopts digital control for all parts of the structure, the UPS performance indicators are very

excellent, and the control system is more stable and reliable; each module has a built-in automatic bypass switch and

the corresponding bypass equalisation inductance, which provides a good performance of the system bypass power

supply equalisation.

Intelligent Battery Management

User-settable charging current, constant current, constant voltage and float charging modes can be automatically

and smoothly switched; battery voltage can be arbitrarily configured (192VDC/ 204VDC/ 216VDC/ 240VDC

32/34/36/38/40-section selectable).

N+X parallel redundancy

The number of redundant modules can be set arbitrarily, when the number of redundant modules reaches two

or more, the system availability reaches 99.999% MTBF (Mean Time Between Failure) up to 250,000 hours or

more; support for the parallel connection between cabinets, the maximum number of parallel cabinets is 4

cabinets; parallel can be shared with the battery pack.

High power density modular design

Module capacity 20kVA/25kVA/30kVA, all modules are 3U in height; UPS modules can be added and removed online, achieving

"zero"maintenance time.

19-inch standard cabinet

Adopting 19-inch standard cabinets, the appearance is beautiful and generous, can perfectly match the application

environment of the server room, saving the use of the server room area; 1. 4-metre-high cabinets to install five modules,

2-metre-high cabinets to install 10 modules.

LCD colour display

Large 10.4"LCD display with touch control, bilingual Chinese/English; single-module LED display.

Safe and convenient maintenance

In the event of an emergency, the power supply can be switched to the maintenance bypass, allowing maintenance

personnel to carry out repairs safely on-line; emergency shutdown can be performed by pressing the EPO button in

the event of an emergency; and there is a Remote Emergency Power Off (REPO) function.

Intelligent Management

Centralized monitoring module (with hot-swappable function) RS232/RS485 communication interface / SNMP card (optional),

can realize the remote monitoring of UPS.
